Product Description
-
H.265 /H.265 dual-stream video compression
-
Supports Full-channel AI-Coding
-
Supports HDCVI/AHD/TVI/CVBS/IP video inputs
-
Max 12 channels IP camera inputs, each channel up to 6MP; Max 64 Mbps incoming bandwidth
-
Up to 1 channel video stream ( analog channel ) Perimeter Protection
-
Up to 8 channels video stream ( analog channel ) SMD Plus
-
Up to 1 channel video stream (analog channel ) human face recognition
-
IoT & POS functionalities
-
Functions
-
Real Time Face Recognition
-
Perimeter Protection
-
SMD Plus
-
AI Coding
-
Smart H.265
-
HDCVI/AHD/TVI/CVBS Auto-detect
-
High Definition Camera Input
-
Coaxial Audio/Upgrade/Alarm
-
Long Distance Transmission
-
AI Search
Product Specification
|
Brand |
Dahua |
|
Product Type |
Digital Video Recorder |
|
Product Model |
DH-XVR5108HS-I3 |
|
Series |
WizSense |
|
System |
|
|
Main Processor |
Embedded processor |
|
Operating System |
Embedded linux |
|
Perimeter Protection |
|
|
Performance |
1 channel, 10 IVS for each channel |
|
Object Classification |
Human/Vehicle secondary recognition for tripwire and intrusion |
|
AI Search |
Search by target classification (Human, Vehicle) |
|
Face Recognition |
|
|
Performance |
Max 8 face pictures/sec processing |
|
1 channel video stream face recognition, only support analog camera |
|
|
Stranger Mode |
Detect strangers' faces (not in device's face database). Similarity threshold can be set manually |
|
AI Search |
Up to 8 target face images search at same time, similarity threshold can be set for each target face image |
|
Database Management |
Up to 10 face databases with 10,000 face images in total. Name, gender, birthday, address, certificate type, cerificate No., countries®ions and state can be added to each face picture |
|
Database Application |
Each database can be applied to video channels independently |
|
Trigger Events |
Buzzer, Voice Prompts, Email, Snapshot, Recording, Alarm Out, PTZ Activation, etc. |
|
SMD Plus |
|
|
Performance |
8 channels |
|
AI Search |
Search by target classification (Human, Vehicle) |
|
Video And Audio |
|
|
Analog Camera Input |
8 channels, BNC |
|
HDCVI Camera Input |
5MP, 4MP, 1080p@ 25/30 fps, 720p@ 50/60 fps, 720p@ 25/30 fps |
|
AHD Camera Input |
5MP, 4MP, 1080p@ 25/30 fps, 720p@ 25/30 fps |
|
TVI Camera Input |
5MP, 4MP, 1080p@ 25/30 fps, 720p@ 25/30 fps |
|
CVBS Camera Input |
PAL/NTSC |
|
IP Camera Input |
8 4 channels, each channel up to 6MP |
|
Audio In/Out |
1/1, RCA |
|
Two-Way Talk |
Reuse audio in/out, RCA |
|
Recording |
|
|
Compression |
AI Coding/H.265 /H.265/H.264 /H.264 |
|
Resolution |
5M-N; 4M-N; 1080p; 1080N; 720p; 960H; D1; CIF |
|
Record Rate |
Main stream: All channel 5M-N (1 fps–10 fps); 4M-N/1080p (1 fps–15 fps); 1080N/720p/960H/ D1/CIF (1 fps–25/30 fps) Sub stream: D1/CIF (1 fps–15 fps) |
|
Bit Rate |
32 kbps–6144 kbps per channel |
|
Record Mode |
Manual; Schedule (General, Continuous); MD (Video detection: Motion Detection, Video Loss, Tampering); Alarm; Stop |
|
Record Interval |
1 min–60 min (default: 60 min), Pre-record: 1 s–30 s, Post-record: 10 s–300 s |
|
Audio Compression |
$
